Heated Bed
For improved filament adhesion
HEATED BED
For improved filament adhesion
LEVEL WIZARD
Steps you through levelling the bed
Level Wizard
Steps you through levelling the bed
Touchscreen Monitor
With intuitive menus and controls
TOUCHSCREEN MONITOR
With intuitive menus and controls
Gallery
Features
- Touch Screen Monitor
- Heated Print Bed
- Level Wizard
- Robust Construction
- Large Print Area
- Print Directly From SD Cards
Tech Specs
Printing
- Print Technology: Fused Filament Fabrication (FFF)
- Build Volume: 200 x 200 x 180mm
- Layer Resolution: 0.1 – 0.4mm
- Positioning Accuracy: X 0.012mm/ Y 0.012mm/Z 0.004mm
- Extruder Quantity: Single Extruder
- Extruder Diameter: 0.4mm
- Print Speed: 10mm/s – 70mm/s
- Travel Speed: 10mm/s – 70mm/s
- Supported Print Materials: Cocoon Create Branded PLA, ABS, PVA, HIPS, PLA Wood, PLA Flex, ConductiveX 0.012mm/ Y 0.012mm/Z 0.004mm
- Extruder Quantity: Single Extruder
- Extruder Diameter: 0.4mm Print Speed: 10mm/s – 70mm/s Travel Speed: 10mm/s – 70mm/s
- Supported Print Materials: Cocoon Create Branded PLA, ABS, PVA, HIPS, PLA Wood, PLA Flex, Conductive
Temperature
- Ambient Operating Temperature: 15°C – 30°C
- Operational Extruder Temperature: 170ºC – 255ºC
- Operational Print Bed Temperature: 15ºC – 109ºC
Software
- Slicer Software: Cura
- Cura Input Formats: .STL, .OBJ, .DAE, .AMF
- Cura Output Format: .GCODE
- Connectivity: SD Card, USB port (Expert users only)
Other
- 200-240VAC, 50/60Hz, 2.0A
- Printer Frame Dimensions: 400 x 410 x 400mm
- Weight: 10KG
