8CH DVR

View on a Mobile or Tablet

Free iOS and Android apps available

FPV Transmission

View the skies through your Android or iOS device

Headless Mode

Easily maintain orientation during flight

Motion Detection

Only record when you need to

HD 720P Camera

Record high quality videos and photos

NIGHT VISION

Record in real time to built-in HDD

Slider
View on a Mobile or Tablet

Free iOS and Android apps available

FPV Transmission

View the skies through your Android or iOS device

Headless Mode

Easily maintain orientation during flight

Motion Detection

Only record when you need to

HD 720P Camera

Record high quality videos and photos

NIGHT VISION

Record in real time to built-in HDD

Slider

Gallery

Features

  • 1TB Hard Drive
  • View on a Mobile or Tablet
  • View on PC
  • HDMI Output
  • Night Vision
  • Wired 720p Cameras
  • Motion Detection
  • Weather Resisitant
  • Mouse Operation

Tech Specs

  • Video Compression H.264
  • Video System NTSC/PAL
  • Operating System Linux (Embedded)
  • Video Input 8 x composite BNC
  • Video Output 1 x BNC composite, 1 x HDMI, 1 x VGA
  • Display Resolution Up to 1920 x 1080
  • Display: Speed 25fps each camera
  • Record: Resolution Up to 720P
  • Record: Speed Selectable from
    1 to 25 fps each channel
  • Recording Modes Continuous, Manual, Motion Detection
  • Live View 1/4/6/8 channel split screen
  • Network LAN, DHCP, Dynamic IP, DDNS and P2P
  • HDD Interface 1 x SATA HDD, up to 4TB
  • Multiplex Operation Live display, Record, Playback, Backup and Network
  • USB 3 x USB (for mouse and backup)
  • PTZ Control Built-in RS485
  • Mobile Surveillance Supports iOS & Android
  • Power Supply DC 12V/2A
  • Image Sensor 1/4″ Colour CMOS Sensor, TVI Signal
  • Video Resolution 720P
  • Video System PAL
  • Infrared IRs 24
  • Day/Night mode Smart IR Cut Filter
  • Night Vision Distance Max 24m
  • Scan Frequency 50Hz
  • Minimum Illumination 0 Lux (IR On)
  • Backlight Compensation Auto
  • Electronic Shutter 1/50~10,000 AUTO
  • Gain Control Auto
  • Lens F=3.6 ~ 60 degrees
  • Operating Temperature -10 – 50C
